ZYA1
Engine style: 157QMJ ,single-cylinder, 4-stroke, air-cooled
Borexstroke (mm): 57.4x57.8
Compression ratio: 9.2:1
Max power (kW/rpm): 7.0/7500
Economic fuel consumption: 2.9L/100km
Fuel tank: 5.0L
Overall dimensions (mm): 1970(L)x665(W)x1100(H)
Wheel base (mm):  1340
Net weight (kg): 112
Max load (kg): 150
Ground clearance (mm): 115
Max speed (kph): 85
Front tire:  130/60-13
Rear tire:  130/60-13
Brake type:  Front disc/Rear drum
Suspension: Front/Rear double shock absorber

COLOR:
Product Description
Specifications
Model: WY125T-125 WY150T-75 WY175T-11
Top Speed (km/h): 80 85 85
Displacement(cc): 124.6 149.6 168.9
Max power  KW(r/rpm): 5.6/7500 7.0/7500 7.6/7000
Overall dimensions (mm): 1970(L)x665(W)x1100(H) 1970(L)x665(W)x1100(H) 1970(L)x665(W)x1100(H)
Economic fuel consumption(L/km): 2.8/100 2.9/100 2.9/100
Tank Capacity (L): 5 5 5
Wheel base (mm): 1340 1340 1340
Ground clearance (mm): 115 115 115
N.W./G.W.  (kg): 112/132 113/133 115/135
Front Tire: 130/60-13 130/60-13 130/60-13
Rear Tire: 130/60-13 130/60-13 130/60-13
Brake Type:
